50-60T Tipper Semi Trailer 3 Axles Blue

Name: 50-60T Tipper Semi Trailer 3 Axles Blue
Brand: CHINA NATIONAL HEAVY DUTY INDUSTRY GROUP LIMITED
SKU: LML9400GYY
Availability: InStock

Rincian produk

Tempat asal: Cina

Nama merek: SINOTERCEL

Sertifikasi: ISO/3C/SGS/BV

Nomor model: LML9400GYY

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 unit

Harga: dapat dinegosiasikan

Kemasan rincian: waxing

Waktu pengiriman: 25 HARI KERJA

Syarat-syarat pembayaran: T/T

Menyediakan kemampuan: 1000 unit/bulan

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                    50-60T tipper semi trailer, 3 axles tipper semi trailer, blue tipper semi trailer


Hidrolik:	sistem hidrolik	Ketebalan:	Dinding samping: 8 mm; Lantai bawah: 10 mm
Panjang Keseluruhan:	7500 mm	Gembong:	Baut JOST Di Pin Raja
Fitur:	Tugas Berat	Pelat bawah:	8mm

Hidrolik:	sistem hidrolik
Ketebalan:	Dinding samping: 8 mm; Lantai bawah: 10 mm
Panjang Keseluruhan:	7500 mm
Gembong:	Baut JOST Di Pin Raja
Fitur:	Tugas Berat
Pelat bawah:	8mm

50-60T Tipper Semi Trailer 3 Axles Blue

50-60T Tipper Semi Trailer 3 Axles Semi Flatbed Trailers Blue

Product Description:

Product features of low flat transport semi-trailer:
The load-carrying surface of the cargo platform of the frame is low, which is suitable for the transportation of various construction machinery and large-scale equipment. It is widely used, efficient and fast.
Reasonable structure: The whole vehicle is optimized by advanced computer-aided design system, and the frame adopts a frame structure combining penetrating beams and I-shaped beams, which has high strength, good rigidity and toughness.
Advanced technology: The longitudinal beam is made of low-alloy steel specially used for automobiles and welded by a fully automatic buried welding machine. The parts of the frame are all shot blasted to enhance the paint adhesion and weather resistance, making the vehicle beautiful and practical.
Suspension system: The tandem independent balance suspension system is adopted to ensure the load balance of each axle.

Parameter:

Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
Model	3 Axles 60Tons
Axle	FUWA brand, 16ton, 3 Sets
Cargo Body	1050023001500mm, floor:10mm, side:6mm
Material	Carbon steel or Mn steel
Gross vehicle weight	75000kgs
King pin	#90
Support leg	JOST Standard 28T
Suspension	Normal suspension
Thickness leaf spring	10/10/10
Tire/Rim	1200R20, 13pcs, 8.5, 12 pcs
Brake Chamber	Standard 6 pcs
Spare wheel carrier	2 pcs
Tool box	1 pcs
Electrical System	Chinese standard 24C lighting system
Side Maker Lamp	LED lamp
Painting	Polyurethane Paint
Overall dimension	12000×2500×3880(mm)
Color	White, red, green, golden and so on.
Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
